Technical specification
Created by EBCCW 00:06
9 8050179
2.2 Ordering information
XLUT 45 D, XLUT 45 M, XLUT 45 C, XLUT 90 D, XLUT 90 M and XLUT 90 C.
Question Choices Description code
Right/Left
Sensors
Photo eyes
RFID
Configuration example
One of the six above mentioned modules has to be chosen first. Then the
questions in the configurator have to be answered.
Example of configurator string: Left-S-PE-2-RF
The choice sensor "Yes" includes sensors and brackets for indicating:
• Pallet in stop position.
The choice sensor "No" includes:
• Sensor bracket for pallet in stop position.
Sensors and brackets that always are included:
• Position of arm (in diverter and combined divert/merge modules).
The choice photoeyes "Yes" includes:
• Photoeyes
• Brackets for photoeyes (8050137).
• Reflectors (8050114)
The choice photoeyes "No" includes no brackets or reflectors.
The choice RFID "Yes" includes:
• Read/write head (5058152).
• Read/write head bracket (8050112).
Right/Left Right/Left
Yes/No S/N
Yes/No PE-2/N
Yes/No RF/N
