19 Chapter 2
2.3 Floppy Drive Connector (FDD1)
You can attach up to two floppy disk drives to the PCE-5120's on board
controller. You can use 3.5" (720 KB, 1.44 MB) drives.
The single board computer comes with a 34-pin daisy-chain drive con-
nector cable. On one end of the cable is a 34-pin flat-cable connector. On
the other end are two sets of 34-pin flat-cable connector (usually used for
3.5" drives). The set on the end (after the twist in the cable) connects to
the A: floppy drive. The set in the middle connects to the B: floppy drive.
JFP3
JFP2
JFP1
LPT1
FDD1
