Appendix B
B.10 External Speaker Connector (JFP2 / SPEAKER)
B.11 Reset Connector (JFP1 / RESET)
Table B.10:External Speaker Connector (JFP2 / SPEAKER)
Pin
Signal
1
SPK+
2
NC
3
SPK_IN
4
SPK-
Table B.11:Reset connector (JFP1 / RESET)
Pin
Signal
1
RESET #
2
GND
