B.12 HDD LED (JFP2 / HDDLED)

B.13 ATX Soft Power Switch (JFP1 / PWR_SW)

Table B.12:HDD LED (JFP2 / HDDLED)

Pin

Signal

1

IDE LED+

2

IDE LED-

Table B.13:ATX soft power switch

(JFP1 / PWR_SW)

Pin

Signal

1

5VSB

2

PWR-BTN
