7 Chapter 1
JOBS1 HW Monitor Alarm
Close: Enable OBS Alarm
Open: Disable OBS Alarm
LAN1 Giga LAN RJ45 connector
LAN2 Giga LAN RJ45 connector
AC97 AC'97 Link connector
SATA1 Serial ATA1
SATA2 Serial ATA2
SATA3 Serial ATA3
SATA4 Serial ATA4
LANLED1 LAN1 and LAN2 LED connector
BMC1 BMC connector
USB12 Two USB port pin headers
USB34 Two USB port pin headers
EXPCI1 HIROSA Extended PCI connector (Optional)
Table 1.2: Connectors
Label Function
