44
A. POWER MALFUNCTIONS
1. Main Disconnect Will Not Turn On
a. PROBABLE CAUSES;
1) Sprinkler isolated power source “OFF” or disabled.
2) OL12 tripped or sprinkler circuit defective.
3) Sprinkler activated.
4) Sprinkler will not reset.
b. POSSIBLE SOLUTIONS;
1) Verify “red” “Sprinkler Power” on main panel to be illuminated.
• If “ON” go to paragraph #3 below
• If “NOT ON” verify isolated sprinkler power source to the dryer
Check sprinkler supply voltage at TB1 Pin #4 and Pin #5
• If “OK” go to paragraph #2 below
• If none, check incoming line voltage
• If none, check fuse disconnect switch
2) Check if OL12 has tripped.
• If “OK” go to paragraph #3 below
• If tripped, check sprinkler circuit, then reset and test.
3) Check if sprinkler is activated...is the “SPRINKLER RESET” button “lit”?
• If “YES,” press “SPRINKLER RESET”
Does the sprinkler reset?
• If “YES,” attempt to turn “ON” the main disconnect again
• If “NO” go to paragraph #4 below and on page 45
4) Sprinkler will not reset, verify that the sprinkler hi-limit has not tripped. (“GREEN” light is off.)
• If it has not tripped, check setting to be 550º F (273º C) and verify that the sprinkler RTD
(Resistive Temperature Device) is connected and has 100 ohms (100 W) at 32º F (0º C)/109
ohms (109 W) at 75º F (24º C)
