Datamax-O'Neil Performance series Media Hub User Manual
Page 9
2 | Media Hub Installation Instructions
Media Hub Installation Guide
8
6. Loosen and remove the three (3) 2.5mm hex head screws securing the right side
cover to the printer chassis.
Figure: 2 - 6 Right Side Screws
7. Lift and remove the cover assembly from the printer chassis.
Caution:
Exercise caution when removing the cover set assembly and secure it in a safe
position where it will not be damaged.
Figure: 2 - 7 Lift Cover Assembly
