Datamax-O'Neil Performance series Media Hub User Manual
Page 7
2 | Media Hub Installation Instructions
Media Hub Installation Guide
6
1. Open the media cover assembly.
2. If the present sensor option is installed on the cover, gently pry the sides of the
cable chain outward to disconnect it from the present sensor cable connection
cover.
Note:
If there is no present sensor mounted on the media cover, continue to step 5.
Figure: 2 - 3 Cable Chain Disconnect
Note:
To clarify the illustration above, the cable chain is shown disconnected from the
printer chassis backbone.
