Introduction
Pearleye Technical Manual V2.3.0
9
• Chapter Camera interfaces on page 25 describes the control junction (I/O
pin assignment), inputs / outputs and trigger features.
• Chapter Image processing on page 34 describes the function of the
Pearleye P-007 LWIR / Pearleye P-030 LWIR firmware. It is related to the
individual modules of image processing and shows in what way the user
can control these modules via the serial interface.
• Chapter Basic parameters and commands on page 39 describes the basic
configuration options and general commands available for the user, being
important for the operation of an ex factory preconfigured camera. Most
probably this information will be sufficient for most users.
• Chapter Advanced parameters and commands on page 46 describes the
advanced configuration of the Pearleye P-007 LWIR / Pearleye P-030
LWIR models. For the control of an ex-factory set up camera the
intervention within the parameters stated here or rather the use of the
mentioned commands is only necessary in exceptional cases.
• The appendix: Chapter Command reference on page 65 describes the
general command reference of the Pearleye P-007 LWIR /
Pearleye P-030 LWIR firmware.
• Chapter Index on page 83 gives you quick access to all relevant data in
this manual.
Conventions used in this manual
To give this manual an easily understood layout and to emphasize important
information, the following typographical styles and symbols are used:
Styles
Style Function Example
Bold Programs, inputs or highlighting
important things bold
Courier Code listings, camera output etc. Output
Courier bold Commands sent to the camera Command
Upper case Register REGISTER
Italics Modes, fields Mode
Table 2: Styles
