Advanced parameters and commands
Pearleye Technical Manual V2.3.0
58
The table below illustrates the possible values for the individual bit groups:
Example
Integration of 32 images simultaneously to the output of the actual integration
image and copy as a reference image
A into the correction data memory (a=1,
b=6, c=1) => yyxxxw = 011101 binary = 0x1D. As soon as the integration is ter-
minated, one still has to wait for at least two image cycles, before the copy pro-
cedure is ended.
> H=1D[CR]
H 0
Operation Mode
Integrator/Image Store
F E D C B A 9 8 7 6 5 4 3 2 1 0
- - - - - - - - d - c c b b b a
ro rw rw rw rw rw rw
Bit group Value (hex) Description
a
0 Output: deactivated. Data are passed through transparently.
1 Output: activated. Output of actual image store content.
b
0 Integration: deactivated. The image store content is not changed.
1 Integration: 1 image. The following image is copied into the image
store.
4 Integration: 8 images. The following 8 images are integrated and the
result is copied into the image store.
5 Integration: 16 images. The following 16 images are integrated and the
result is copied into the image store.
6 Integration: 32 images. The following 32 images are integrated and the
result is copied into the image store.
7 Integration: 64 images. The following 64 images are integrated and the
result is copied into the image store.
c
0 Copy: deactivated.
1 Copy: Target A. The image store content of the integrator is copied into
the correction data store as cold reference image of the two point cor-
rection.
2 Copy: Target B. The image store content of the integrator is copied into
the correction data store as warm reference image of the two point cor-
rection.
d
0 Integration completed. (This value can only be read out.)
1 Integration still running. (This value can only be read out.)
Note: The Integration is activated by change of the register content of H. If e.g. directly following
the integration of 64 images a further integration of 64 images is started, another value has to be
written into the register first.
Example: H=E, H=0, H=E.
Table 29: Integrator and image store: values
