Specifications
Pearleye Technical Manual V2.3.0
14
Measurement temperature
range -20 °C to +80 °C (standard version)
0 °C to +200 °C (High Temp version)
Sensitivity (NETD) typical
80 mK @ 303 K @ f/1.0 (standard version)
typical
160 mK @ 303 K @ f/1.0 (High Temp version)
Temperature stabilization Peltier stabilized
ADC 14 bit
Digital output Internal 14 bit, output only 12 bit, GigE
Sensor time constant approx. 7 ms
Pixel clock 5.25 MHz
Smart features Built-in correction data sets, bad pixel correction, background (FPN)
correction, gain/offset correction (NUC/non-uniformity correction) for
each pixel, drift compensation, temperature linearization (LUT), contin-
uous mode (image acquisition with maximum frame rate)
With AVT‘s AcquireControl: pseudo color LUT with several color profiles,
auto contrast, auto brightness, temperature measurement, analyze mul-
tiple regions (rectangular, circle, ring, line) within image, real-time sta-
tistics and histogram, background (FPN) correction
Digital interface IEEE 802.3 1000BASE-T (GigE Vision V1.2)
Power requirements + 12 V, -0% / +5%, max. 1.5 A (during camera start-up: inrush current
≥ 4 A for 20 ms, capacitive load < 2000 μF)
Dimensions With 18 mm f/1.0 lens: 133.7 mm x 90 mm x 86 mm (L x W x H); incl. con-
nectors
Mass 830 g (with 18 mm f/1.0 lens)
Housing material Aluminum alloy (AlMgSi1)
Operating temperature
(Reference to the internal
temperature sensor) +15 °C to +50 °C
Optimal working range
(Reference to the internal
temperature sensor) +25 °C to +45 °C
Ambient temperature during
storage -30 °C to +70 °C
Relative humidity
(operating and storage) 10 % to 95 % without condensation
Shock 25 g
Vibration 2 g
Feature Specification
Table 3: Specification Pearleye P-007 LWIR / P-007 LWIR High Temp
