ALLIED Vision Technologies Pearleye P-030 LWIR User Manual
Page 21
Camera dimensions
Pearleye Technical Manual V2.3.0
21
LED
Color
Description
Power
Green
Power indicator
L2
Red
Camera is operational
L3
Red
Temperature state
Off means: temperature is ok
L4
Red
Trigger (reset) input activity
L5
Red
Frame output activity
Table 5: Description of LEDs: Pearleye P-007 LWIR / Pearleye P-030 LWIR
