Advanced parameters and commands
Pearleye Technical Manual V2.3.0
50
Bit position 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Value (12-bit)
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0 - - - -
a 0
Value (14-bit)
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0 - -
a 0
Table 19: J and K: bit usage
GigE Vision feature name Feature Visibility Description
TPC_OperationMode Expert Operation mode of the two-point
correction
(E= command)
TPC_CorrectionData_FileNumber Expert File number of the flash file
containing the set values for the
two-point correction.
(N= command)
TPC_SetValue_LowRef Expert Define the set value for the low
reference image of the two-point
correction.
(J= command)
TPC_SetValue_HighRef Expert Define the set value for the high
reference image of the two-point
correction.
(K= command)
TPC_FirstImage_LowRef Expert File number of the first low
reference image of the two-point
correction.
(A= command)
TPC_FirstImage_HighRef Expert File number of the first high
reference image of the two-point
correction.
(B= command)
Table 20: GigE feature: TwoPointCorrection (TPC)
