Introduction
Pearleye Technical Manual V2.3.0
7
continued from previous page
V2.1.0
[continued]
23.01.12
[continued]
Some smaller corrections:
• Inserted different temperatures for Pearleye P-030 LWIR
and Pearleye P-007 LWIR) in Chapter
Sensor temperature
too low (pin 12, 13) on page 27
• Inserted values for High Temp version in Chapter Conver-
sion of image data to temperature data on page 29
• Emissivity correction in Formula 1: Emissivity correction on
page 31
• File numbers 128-129 instead of 128 in Chapter Upload a
file to flash (Q) on page 61
V2.1.1 27.01.12 Some minor corrections:
• Corrected lens f stop values of Pearleye P-007 LWIR /P-007
LWIR High Temp in
Table 3: Specification Pearleye P-007
LWIR / P-007 LWIR High Temp on page 13
• Added note, that cameras are only available with
integrated lens: see
–
Table 3: Specification Pearleye P-007 LWIR / P-007 LWIR
High Temp
on page 13
– Table 4: Specification Pearleye P-030 LWIR on page 16
2.2.0 02 May 2012 • Added ring, line in all specifications tables at description of
smart features: analyze multiple regions (rectangular, circle,
ring, line) within image: see Chapter
Specifications on page
13
• Updated Transmission curves (legend contains
Transmission): see Chapter
Spectral transmission on page 19
• Corrected: All models are equipped with multiple correction
data sets.
– Chapter
Adjust the image processing on page 24
– Chapter Select a correction data set (S) on page 39
• Added description for heating up the camera in Chapter
Sensor temperature too low (pin 12, 13) on page 27
• More precise description: camera housing temperature
instead of camera temperature in Chapter
Sensor
temperature too high (pin 14) on page 28
• Added cross-reference to emission ratio in Chapter
Correction data on page 36
• Added cross-reference to correction data set in Chapter Cor-
rection sets on page 36
to be continued on next page
Version Date Description
Table 1: Document history
