Basic parameters and commands
Pearleye Technical Manual V2.3.0
41
The following Pearleye P-007 LWIR table shows an overview of the time
required by the command
k=0:
T = Time for one frame-out (Pearleye P-007 LWIR: 25ms)
N1 = Number of data sets (max. 32)
N2 = Number of integrated images (max. 64)
The following Pearleye P-030 LWIR table shows an overview of the time
required by the command
k=0:
GigE feature name (CameraSpecialFeatures) Feature Visibility Description
AutoCalibrateOnce Beginner Start the automatic calibration
once.
(k=0 command)
The processing of this com-
mand can take several seconds,
depending on the current
image rate and the number of
correction data sets available.
Table 11: GigE feature: AutoCalibrateOnce
Description Time Max. Time Typical time for a Pearleye P-007 LWIR
Close shutter (optional) 4 * T 100 ms 0 ms
Save one image 3 * T 75 ms 75 ms
Open shutter (optional) 0 * T 0 ms 0 ms
Choose data set N1 * 2 * T 1600 ms 800 ms (N1=16)
Close shutter 5 * T 125 ms 125 ms
Integrate images (N2 + 1) * T 1625 ms 1625 ms
Open shutter 0 * T 0 ms 0 ms
Calculate statistics 2 * T 50 ms 50 ms
Total time 3.58s 2.68s
Table 12: Pearleye P-007 LWIR: time required by command k=0
Description Time Max. Time Typical time for a Pearleye P-030 LWIR
Close shutter (optional) 4 * T 166 ms 0 ms
Save one image 3 * T 125 ms 125 ms
Open shutter (optional) 0 * T 0 ms 0 ms
Table 13: Pearleye P-030 LWIR: time required by command k=0
