Specifications
Pearleye Technical Manual V2.3.0
15
Regulations CE, RoHS (2011/65/EU)
Options • Suitable lenses for LWIR with various focal lengths:
12 mm lens, f/0.85, FOV: 50.0° x 38.6°
18 mm lens, f/1.0,
FOV: 34.6° x 26.3°
22 mm lens, f/1.2, FOV: 28.6° x 21.6°
35 mm lens, f/1.0, FOV: 18.2° x 13.7°
75 mm lens, f/1.0, FOV: 8.5° x 6.4°
• Different temperature ranges
Feature Specification
Table 3: Specification Pearleye P-007 LWIR / P-007 LWIR High Temp
Note

The cameras are available with integrated lens
only. Therefore the customer cannot change the
lens. Changing lens and calibration has to be
done in the AVT factory.
