Programming the Mio R-4
70
Mio Modero R-4
? Button Query Commands (Cont.)
?ICO
Get the current
icon index
Syntax:
SEND_COMMAND
Variables:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons
(0 = All states, for General buttons 1 = Off state and 2 = On state).
• custom event type = 1003:
Flag - Zero
Value1 - Button state number
Value2 - Icon index
Value3 - Zero
Text - Blank
Text length - Zero
Example:
SEND COMMAND Device,"'?ICO-529,1'"
Gets the button 'OFF state' icon index information.
The result sent to the Master would be:
ButtonGet Id = 529 Type = 1003
Flag = 0
VALUE1 = 2
VALUE2 = 12
VALUE3 = 0
TEXT =
TEXT LENGTH = 0
?JSB
Get the current
bitmap
justification
Syntax:
SEND_COMMAND
Variables:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons
(0 = All states, for General buttons 1 = Off state and 2 = On state).
• custom event type = 1005:
Flag - Zero
Value1 - Button state number
Value2 - 1 - 9 justify
Value3 - Zero
Text - Blank
Text length - Zero
Example:
SEND COMMAND Device,"'?JSB-529,1'"
Gets the button 'OFF state' bitmap justification information.
The result sent to the Master would be:
ButtonGet Id = 529 Type = 1005
Flag = 0
VALUE1 = 1
VALUE2 = 5
VALUE3 = 0
TEXT =
TEXT LENGTH = 0
