Programming the Mio R-4
64
Mio Modero R-4
"^" Button Commands (Cont.)
^TEF
Set the text effect.
Set the text effect. The Text Effect is specified by name and can be found in TPD4.
Syntax:
"'^TEF-
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
• text effect name = Refer to theText Effects table on page 40 for a listing of text
effect names.
Example:
SEND_COMMAND Device,"'^TEF-500.504&510.515,1&2,Soft Drop Shadow
3'"
Sets the text effect to Soft Drop Shadow 3 for the button with variable text range 500-504
and 510-515.
^TXT
Assign a text
string to those
buttons with a
defined address
range
Assign a text string to those buttons with a defined address range. Sets Non-Unicode text.
Syntax:
"'^TXT-
Variables:
• variable text address range = 1 - 4000.
• button states range = 1 - 2 (1 = Off state, 2 = On state).
• new text = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Device,"'^TXT-500.504&510.515,1&2,Test Only'"
Sets the On and Off state text for buttons with the variable text ranges of
500-504 & 510-515.
^UNI
Set Unicode text
Set Unicode text. For the ^UNI command (%UN and ^BMF command), the Unicode text
is sent as ASCII-HEX nibbles.
Syntax:
"'^UNI-
Variables:
• variable text address range = 1 - 4000.
• button states range = 1 - 2 (1 = Off state, 2 = On state).
• unicode text = Unicode HEX value.
Example:
SEND_COMMAND Device,"'^UNI-500,1,0041'"
Sets the button’s unicode character to ’A’.
Note: To send the variable text ’A’ in unicode to all states of the variable text
button 1, (for which the character code is 0041 Hex), send the following command:
SEND_COMMAND Device,"'^UNI-1,0,0041'"
Note: Unicode is always represented in a HEX value.
