Programming the Mio R-4
62 Mio Modero R-4
"^" Button Commands (Cont.)
^JSB
Set bitmap/

picture alignment
using a numeric

keypad layout for
those buttons with
a defined address
range
Set bitmap/picture alignment using a numeric keypad layout for those buttons with a
defined address range.The alignment of 0 is followed by ',,'. The left and top
coordinates are relative to the upper left corner of the button.
Syntax:
"'^JSB-,,alignment>'"Variable: • variable text address range = 1 - 4000.• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons1 = Off state and 2 = On state).• new text alignment = Value of 1- 9 corresponds to the following locations: Example:SEND_COMMAND Device,"'^JSB-500.504&510.515,1&2,1'"Sets the off/on state picture alignment to upper left corner for those buttons with variable
text ranges of 500-504 & 510-515.^JSISet icon alignment using a
numeric keypad
layout for those buttons with a
defined address
rangeSet icon alignment using a numeric keypad layout for those buttons with a defined
address range. The alignment of 0 is followed by ',,'. The left and top coordi-
nates are relative to the upper left corner of the button.Syntax: "'^JSI-,,alignment>'"Variable: • variable text address range = 1 - 4000.• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons1 = Off state and 2 = On state). • new icon alignment = Value of 1 - 9 corresponds to the following locations: Example:SEND_COMMAND Device,"'^JSI-500.504&510.515,1&2,1'"Sets the Off/On state icon alignment to upper left corner for those buttons with variable
text range of 500-504 & 510-515.1478963250Zero can be used for an absolute position1478963250Zero can be used for an absolute position
alignment>'"
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 
1 = Off state and 2 = On state).
• new text alignment = Value of 1- 9 corresponds to the following locations:
Example:
SEND_COMMAND Device,"'^JSB-500.504&510.515,1&2,1'"
Sets the off/on state picture alignment to upper left corner for those buttons with variable
text ranges of 500-504 & 510-515.
^JSI
Set icon

alignment using a
numeric keypad
layout for those

buttons with a
defined address
range
Set icon alignment using a numeric keypad layout for those buttons with a defined
address range. The alignment of 0 is followed by ',,'. The left and top coordi-
nates are relative to the upper left corner of the button.
Syntax:
"'^JSI-,
alignment>'"
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 
1 = Off state and 2 = On state).
• new icon alignment = Value of 1 - 9 corresponds to the following locations:
Example:
SEND_COMMAND Device,"'^JSI-500.504&510.515,1&2,1'"
Sets the Off/On state icon alignment to upper left corner for those buttons with variable
text range of 500-504 & 510-515.
1
4
7 8 9
6
3 2
5
0
Zero can be used for an absolute position
1
4
7 8 9
6
3 2
5
0
Zero can be used for an absolute position
