Programming the Mio R-4
61 Mio Modero R-4
"^" Button Commands (Cont.)
^GSN
Change the

bargraph slider
name or joystick
cursor name
Change the bargraph slider name or joystick cursor name. Slider names and cursor
names can be found in the TPDesign4 slider name and cursor drop-down list.
Syntax:
"'^GSN-,'"
Variable:
• variable text address range = 1 - 4000.
• bargraph slider name = See table below.
Example:
SEND_COMMAND Device,"'^GSN-500,Ball'"
Changes the bargraph slider name or the Joystick cursor name to ’Ball’.
^ICO
Set the icon to a
button
Set the icon to a button.
Syntax:
"'^ICO-,,'"Variable: • variable text address range = 1 - 4000.• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons1 = Off state and 2 = On state).• icon index range = 0 - 9900 (a value of 0 is clear).Example:SEND_COMMAND Device,"'^ICO-500.504&510.515,1&2,1'"Sets the icon for On and Off states for buttons with variable text ranges of 500-504 & 510-515.Bargraph Slider Names:Circle -MNoneCircle -SBallPrecisionCircle -LRectangle -LRectangle -MRectangle -SWindowsWindows ActiveJoystick Cursor Names:CircleNoneCrosshairsArrowGunsightBallHandMetalSpiralTargetView Finder
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 
1 = Off state and 2 = On state).
• icon index range = 0 - 9900 (a value of 0 is clear).
Example:
SEND_COMMAND Device,"'^ICO-500.504&510.515,1&2,1'"
Sets the icon for On and Off states for buttons with variable text ranges of 500-504 & 
510-515.
Bargraph Slider Names:
Circle -M
None
Circle -S
Ball
Precision
Circle -L
Rectangle -L Rectangle -M Rectangle -S
Windows Windows Active
Joystick Cursor Names:
Circle
None
Crosshairs
Arrow
Gunsight
Ball
Hand Metal Spiral
Target View Finder
