Programming the Mio R-4
49 Mio Modero R-4
"^" Button Commands
These Button Commands are used in the NetLinx protocol and are case insensitive.
All commands that begin with "^" have the capability of assigning a variable text address range and
button state range. A device must first be defined in the NetLinx programming language with values
for the Device: Port: System (in all programming examples - Remote is used in place of these values).
 Variable text ranges allow you to target one or more variable text channels in a single
command.
 Button State ranges allow you to target one or more states of a variable text button with a
single command.
 The "." Character is used for the 'through' notation, also the "&" character is used for the
'And' notation.
"^" Button Commands
^ANI
Run a button 
animation

(in 1/10 second)
Run a button animation (in 1/10 second).
Syntax:
"'^ANI-,,,'"
Variable:
• variable text address range = 1 - 4000.
• start state = Beginning of button state (0= current state).
• end state = End of button state.
• time = In 1/10 second intervals.
Example:
SEND_COMMAND Panel,"'^ANI-500,1,25,100'"
Runs a button animation at text range 500 from state 1 to state 25 for 10 second.
^APF
Add page flip
action to a button
if it does not
already exist
Add page flip action to a button if it does not already exist.
Syntax:
"'^APF-,,'"
Variable:
• variable text address range = 1 - 4000.
• page flip action = Stan[dardPage] - Flip to standard page

Prev[iousPage] - Flip to previous page 
Show[Popup] - Show Popup page

Hide[Popup] - Hide Popup page 
Togg[lePopup] - Toggle popup state

ClearG[roup] - Clear popup page group from all pages

ClearP[age] - Clear all popup pages from a page with the 
specified page name

ClearA[ll] - Clear all popup pages from all pages
• page name = 1 - 50 ASCII characters.
Example:
SEND COMMAND Device,"'^APF-400,Stan,Main Page'"
Assigns a button to a standard page flip with page name 'Main Page'.
