Programming the Mio R-4
63 Mio Modero R-4
"^" Button Commands (Cont.)
^JST
Set text

alignment using a
numeric keypad
layout for those
buttons with a
defined address
range
Set text alignment using a numeric keypad layout for those buttons with a defined address
range. The alignment of 0 is followed by ',,'. The left and top coordinates are
relative to the upper left corner of the button.
Syntax:
"'^JST-,,alignment>'"Variable: • variable text address range = 1 - 4000.• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons1 = Off state and 2 = On state). • new text alignment = Value of 1 - 9 corresponds to the following locations: Example:SEND_COMMAND Device,"'^JST-500.504&510.515,1&2,1'"Sets the text alignment to the upper left corner for those buttons with variable text ranges
of 500-504 & 510-515.^SHOShow or hide a
button with a set
variable text
rangeShow or hide a button with a set variable text range.Syntax: "'^SHO-,'"Variables: • variable text address range = 1 - 4000.• command value = (0= hide, 1= show).Example:SEND_COMMAND Device,"'^SHO-500.504&510.515,0'"Hides buttons with variable text address range 500-504 & 510-515.^TECSet the text effect
color for the specified
addresses/states
to the specified
colorSet the text effect color for the specified addresses/states to the specified color. The Text
Effect is specified by name and can be found in TPD4. You can also assign the color by
name or RGB value (RRGGBB or RRGGBBAA).Syntax: "'^TEC-,,'"Variable: • variable text address range = 1 - 4000.• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons1 = Off state and 2 = On state). • color value = Refer to theRGB Values for all 88 Basic Colors table on page 35.Example:SEND_COMMAND Device,"'^TEC-500.504&510.515,1&2,12'"Sets the text effect color to Very Light Yellow on buttons with variable text 500-504 and 510-515. 1478963250Zero can be used for an absolute position
alignment>'"
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 
1 = Off state and 2 = On state).
• new text alignment = Value of 1 - 9 corresponds to the following locations:
Example:
SEND_COMMAND Device,"'^JST-500.504&510.515,1&2,1'"
Sets the text alignment to the upper left corner for those buttons with variable text ranges
of 500-504 & 510-515.
^SHO
Show or hide a
button with a set
variable text
range
Show or hide a button with a set variable text range.
Syntax:
"'^SHO-,'"
Variables:
• variable text address range = 1 - 4000.
• command value = (0= hide, 1= show).
Example:
SEND_COMMAND Device,"'^SHO-500.504&510.515,0'"
Hides buttons with variable text address range 500-504 & 510-515.
^TEC
Set the text effect
color for the

specified
addresses/states
to the specified
color
Set the text effect color for the specified addresses/states to the specified color. The Text
Effect is specified by name and can be found in TPD4. You can also assign the color by
name or RGB value (RRGGBB or RRGGBBAA).
Syntax:
"'^TEC-,
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state).
• color value = Refer to theRGB Values for all 88 Basic Colors table on page 35.
Example:
SEND_COMMAND Device,"'^TEC-500.504&510.515,1&2,12'"
Sets the text effect color to Very Light Yellow on buttons with variable text 500-504

and 510-515.
1
4
7 8 9
6
3 2
5
0
Zero can be used for an absolute position
