Programming the Mio R-4
57
Mio Modero R-4
"^" Button Commands (Cont.)
^BRD
Set the border of
a button state/
states
Set the border of a button state/states only if the specified border is not the same as the
current border. The border names are available through the TPDesign4 border-name
drop-down list.
Syntax:
"'^BRD-
Variable:
• variable text address range = 1 - 4000.
• button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
• border name = Refer toBorder Styles by Numbers table on page 38.
Example:
SEND_COMMAND Device,"'^BRD-500.504&510.515,1&2,Quad Line'"
Sets the border by name (Quad Line) to those buttons with the variable text range of
500-504 & 510-515.
Refer to theTPD4 Border Styles by Name table on page 38.
^BSF
Set the focus to
the text area
Set the focus to the text area.
Note: Select one button at a time (single variable text address). Do not assign a variable
text address range to set focus to multiple buttons. Only one variable text address can be
in focus at a time.
Syntax:
"'^BSF-
Variable:
• variable text address range = 1 - 4000.
• selection value = Unselect = 0 and select = 1.
Example:
SEND_COMMAND Device,"'^BSF-500,1'"
Sets the focus to the text area of the button.
^BSM
Submit text for
text area buttons.
This command causes the text areas to send their text as strings to the NetLinx Master.
Syntax:
"'^BSM-
Variable:
• variable text address range = 1 - 4000.
Example:
SEND_COMMAND Device,"'^BSM-500'"
Submits the text of the text area button.
^BSP
Set the button
size and position
Set the button size and its position on the page.
Syntax:
"'^BSP-
Variable:
• variable text address range = 1 - 4000.
• left = left side of page.
• top = top of page.
• right = right side of page.
• bottom = bottom of page.
Example:
SEND_COMMAND Device,"'^BSP-530,left,top'"
Sets the button with variable text 530 in the left side top of page.
