5.1.1.2 - STATIC & COMBINED MODES
5.1.1.3 - Wheel ALUM
After measurement for inside F1 as shown, again remove the gauge in order to memorize the data for the outside FE;
keep the position for at least 2 seconds.
Press the button to change the inside weight from adhesive to clip-on.
If the machine detects a difference between the inside and the outside diameter greater than or equal to 2”, the fol-
lowing type of correction is automatically set:
Manual pressetting is possible by using the push buttons as for detailed hereunder.
The STATIC mode is required for motorcycle wheels or when it is not possible to
place the counterweights on the two sides of the rim.
Balancing of light alloy rims with application of adhesive weights on the shoulders of
the rims. The position of the weights is fi xed from the edges of the rim to the inside
of the rim.
Combined balancing: adhesive weight on the outside and clip-on weight on the
inside. The position of the outside weight is fi xed from the outside edge of the rim to
the inside of the rim.
Combined balancing: adhesive weight on the inside and clip-on weight on the
outside. The position of the inside weight is fi xed from the edge of the rim to the
inside of the rim.
Position of
adhesive
weight
Button :
