I 0638 - 13 GB
5.3.3 - UNBALANCE OPTIMIZATION
- This function serves to reduce the amount of weight to be added in order to balance the wheel.
- It is suitable for static unbalance exceeding 30 g.
- It improves the residual eccentricity of the tyre.
- Mark with chalk a reference point on the adapter and rim.
- With the aid of a tyre remover, turn the tyre on he rim by 180°.
- Refi t the wheel with the reference mark coinciding between rim and
adapter.
- Perform a manual spin under normal conditions
- RH display: percentage reduction
- LH display: actual static unbalance which can be reduced by rotation.
- Mark the two positions of the rim and tyre, and turn the tyre on the rim
until the positions correspond in order to obtain the optimization
on the display.
RETURN TO MEASUREMENT SCREEN.
TYRE POSITION
RIM POSITION
Unbalance already measured No previous unbalance
measurement
unbalance measurement
Perform a manual spin
