I 0638 - 14 GB
5.3.4 - ALU AND STATIC MODES
From the measurement screen, press the button to select all the correction types (see AUTOMATIC
PRESETTING) . The (5)-LED displays show the position where to apply the weights. If a spin has already been perfor-
med, the processor automatically recalculates, for each change of mode, the amounts of unbalance according to the
new calculation.
5.3.5 - AUTOMATIC MINIMIZATION OF STATIC UNBALANCE
Initial unbalance
Possible approximations
static residual static residual static residual static residual
With a traditional Choice with minimum
balancing machine static residual
Position
This program is designed to improve the quality of balancing without any mental effort or loss of time by the operator.
In fact by using the normal commercially available weights, with pitch of 5 in every 5 g, and by applying the two counte-
rweights which a conventional wheel balancer rounds to the nearest value, there could be a residual static unbalance
of up to 4 g. The damage of such approximation is emphasized by the fact that static unbalance is cause of most of
disturbances on the vehicle. This new function automatically indicates the optimum entity of the weights to be applied by
approximating them in an “intelligent” way according to their position in order to minimize residual static unbalance.
