I 0638 - 6 GB
See chapter on UNBALANCE OPTIMIZATION
CONFIRM
diameter
mm/inch
width
mm/inch
approximates
1-5g or 0.1-.25 oz
See self-diagnostics chapter
See self-calibration chapter
CONFIRM
CONFIRM
CONFIRM
RETURNS TO MEASUREMENT SCREEN
4.4.1 - CONTROL OF THE FUNCTIONS MENU
Calibration of automatic RIM DISTANCE gauge
Calibration of automatic DIAMETER gauge
approximates
10-50g or .25/1oz
- Provision for setting the balancing machine in car or truck mode:
by pressing button; LED lights up when the machine set to car mode.
- Unbalance display pitch:
Car = 1/5 g (.1/0.25 Oz) Truck = 10/50 g (.25/1 Oz)
When is pressed, the unbalance is displayed with pitch:
Car = 1 g Truck = 10 g
.1 Oz .25 Oz
- Unbalance display threshold
Car = 5 g (.4 Oz) Truck = 50 g (2 Oz)
