ADC Fiber Optic Panel FL2000 Series - Manual (Page 6)

10/07
•
103743AE
Fiber
Optic
Panels
43 w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Rack
Mount
Panel
Solutions
FL2000 Series Fiber Optic Panel
Fiber Termination Panels with Adapters or Pigtails
1
2
4
7
9 12-position 1.75" (1 RU)
24-position 3.5" (2 RU)
48-position 5.25" (3 RU)
72-position 8.75" (5 RU)
96-position 10.5" (6 RU)
Panel Capacity Panel Height
1 LC connectors and adapters double the capacity
of the panel by terminating two fibers at
each adapter.
2 6-fiber softwall bundle except with LC connectors,
which uses 12-fiber.
3 Mounting kit shipped unattached, if other than
standard mounting style.
FL2 -
Catalog Number
0 0 0 -
0
5 Latch
K1 lock
Latch Type
Number
of Ports
Loaded
A
C
D 19" standard
19" flush mount
23" centered
Mounting Style 3
0
SC
LC
1
SC ultra polish
SC angled polish
FC ultra polish
LC ultra polish
1
LC angled polish 1
Multimode
9
6
Singlemode
7
J
2
8
B
Connector and Adapter Type
R
A
P
R
C
Adapter-only
Singlemode or multimode 62.5/125 µm
stranded softwall bundle
Singlemode or multimode 62.5/125 µm
12-fiber ribbon
Multimode 50/125 µm
stranded softwall bundle
Pigtail or Adapter Type 2
126 mm
(5")
257 mm
(10.1")
498 mm
(19.6")
133 mm
(5.25")
Other configurations are available upon request. Please contact ADC Technical Assistance Center.
Features
• Termination-only panel
• VCG ships with each panel
• Uses FL2000 6paks with angled retainers
72-Position Termination Panel 48-Position Termination Panel
