ADC Fiber Optic Panel FL2000 Series - Manual (Page 16)

10/07
•
103743AE
Fiber
Optic
Panels
53 w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Rack
Mount
Panel
Solutions
6pak Adapter Blank
6pak Adapter - Adapters only
Features
• Completely interchangeable between FL2000
panel, FL1000 rack and wall box products
• Can be ordered with all standard types of
adapters and connectors
• Feature ADC‘s removable angled retainers
which provide superior fiber management
• No tools required to install into FL2000 and
FL1000 products
• Can be ordered with adapters only or
for quick and easy installation, with
preterminated three- or five-meter pigtails
FL2000 Series Fiber Optic Panel
Panel Accessories
6pak Adapter
(Shown with Singlemode Simplex Adapters)
6pak Adapter
(Shown with Multimode Simplex Adapters)
O r d e r i n g I n f o r m a t i o n
Description
Multimode
SC
FC
LC*
Singlemode
SC ultra polish
SC angled polish
FC ultra polish
LC ultra polish*
LC angled polish*
6pak blank plug-in
Catalog Number
FL2-6PMMSC
FL2-6PMMFC
FL2-6PMMLC
FL2-6PSMSC
FL2-6PSMASC
FL2-6PSMFC
FL2-6PSMLC
FL2-6PSMALC
FL2-6PBLNK
Other configurations are available upon request. Please contact ADC Technical Assistance Center.
* LC 6pak adapter accommodates 12 LC connectors.
