Rack
Mount
Panel
Solutions
(17.5")
445 mm
(15.9")
404 mm
(17.5")
445 mm
127 mm
(5")
127 mm
(5")
(21.9")
556 mm
(19.6")
483 mm
(18.3")
465 mm
13 mm
(5")
13 mm
(5")
49 mm
(1.9")
(6.7")
169 mm
478 mm
(18.8")
Standard Mount
(as shipped)
Rear Guard Box
(optional with some racks)
Rack shown
for reference
5" (12.7 cm)
Recess Mounting Standard
FLUSH MOUNT
Rear Guard Box
(optional with some racks)
Rack shown
as reference
Catalog Number
FL2-FLMT0175
FL2-FLMT0350
FL2-FLMT0525
FL2-FLMT0700
FL2-FLMT0875
FL2-FLMT1050
FL2-FLMT1400
FL2-FLMT1750
Panel Height
1.75" (1 RU)
3.5" (2 RU)
5.25" (3 RU)
7" (4 RU)
8.75" (5 RU)
10.5" (6 RU)
14" (8 RU)
17.5" (10 RU)
O r d e r i n g I n f o r m a t i o n
Description
Flush mount kit; allows 1", 2" or 4" recess mounting
Kit includes: VCG and mounting flanges
FL2000 Series Fiber Optic Panel
Panel Accessories – 19-Inch Rack Mount Installation Kits
Standard Mount Kit
Flush Mount Kit
Features
• Panels shipped with
- Left-side “L” bracket
- Left-side 2.5" wide vertical cable guide
(VCG)
• Other mounting options are available
upon request. Please contact ADC Technical
Assistance Center.
(17.5")
445 mm
(15.9")
404 mm
(17.5")
445 mm
127 mm
(5")
127 mm
(5")
(21.9")
556 mm
(19.6")
483 mm
(18.3")
465 mm
13 mm
(5")
13 mm
(5")
49 mm
(1.9")
(6.7")
169 mm
478 mm
(18.8")
Standard Mount
(as shipped)
Rear Guard Box
(optional with some racks)
Rack shown
for reference
5" (12.7 cm)
Recess Mounting Standard
FLUSH MOUNT
Rear Guard Box
(optional with some racks)
Rack shown
as reference
Catalog Number
FL2-VCGKIT0175
FL2-VCGKIT0350
FL2-VCGKIT0525
FL2-VCGKIT0700
FL2-VCGKIT0875
FL2-VCGKIT1050
FL2-VCGKIT1400
FL2-VCGKIT1750
Panel Height
1.75" (1 RU)
3.5" (2 RU)
5.25" (3 RU)
7" (4 RU)
8.75" (5 RU)
10.5" (6 RU)
14" (8 RU)
17.5" (10 RU)
O r d e r i n g I n f o r m a t i o n
Description
Standard mount kit
Kit includes: VCG with integrated mounting holes
Standard Mount Kit
Flush Mount Kit
