TG30G

Section C: Comprehensive Troubleshooting

Self-energized alternator may have lost magnetism. Touch steel tool

to shaft to detect any magnetism. Is shaft magnetized?

Momentarily (1 sec.) jumper D+ terminal on
regulator to B+ terminal on alternator. Touch
shaft with steel tool to detect significant magne-
tism. Is shaft magnetized?

Yes

No

Yes

No

Figure 7 – Alternator-to-Regulator Harness Plug

Chart 1 – No Output:

A2-149 Only

Install a jumper from B+ terminal on alternator

to pin F in harness plug. Momentarily (1 sec.)

jumper pin A to B– terminal on alternator.
Touch shaft with steel tool to detect significant

magnetism. Is shaft magnetized?

Yes

No

PIN CONNECTIONS

Pin A

F–

Pin B

Phase

Pin C

B–

Pin D

B+

Pin E

D+

Pin F

F+

Set DMM to diode test. Connect black lead of DMM

to pin E in harness plug. Connect red lead to B-
terminal or alternator. DMM should read voltage

drop. Reverse leads. DMM should read OL.

Alternator is defective.

Yes

No

Go to Chart 3, page 7.

Alternator is defective.

Regulator is defective.

Install a jumper from B+ terminal on alternator

to pin F in harness plug. Momentarily (1 sec.)
jumper pin A to B– terminal on alternator. Touch

shaft with steel tool to detect significant magne-

tism. Is shaft magnetized?

Yes

No

Alternator is defective.

Regulator is defective.

Remove jumper from D+ to B+.

Unplug alternator-to-regulator harness. Connect DMM across pin D and pin C in

harness plug. Does battery voltage exist?

Yes

No

When conducting this step, ensure that the probes do not touch
other pins, as an arc may damage the wiring in the harness.

CAUTION
