TG30G
Figure 3 — C627/C628/C631/C656/C657
Alternator Terminals
B– terminal stud
A2-149: D+ terminal
A2-155: IGN terminal
A2-149: R terminal
A2-155: P terminal B+ terminal stud
(on rear of control unit)




Section A: Alternator Description and Operation
(CONT’D)
Figure 4 — C658 Alternator Terminals
B– terminal stud

IGN terminal
P terminal B+ terminal stud
(on rear of control unit)



Figure 5 — C671 Alternator Terminals
Figure 6 — C680 Alternator Terminals
P terminal
 
IGN terminal

B+ terminal stud
B–
terminal stud

B– terminal stud
IGN terminal
P terminal
B+
terminal stud




