8 Kawasaki Installation
Kawasaki Installation
System
ECU
• M400 Marine ECU
Installation Set
• 1 x Adaptor Loom
• 1 x KTC (K-Line to CAN module)
• 1 x KPE (Pulse Extender)
• 1 x Bosch Ignition Module 200
Mounting Set
• 1 x ECU mounting bracket
• Mounting bolts and screws
• 1 x Ignition Mounting Plate
On request the Kawasaki PWC Plug-In ECU is available with the M800
Marine ECU.
Installation
The M400 Marine ECU replaces the factory ECU on the ECU mounting
bracket which is located behind the front bulkhead in the front storage
compartment. Place the stainless steel clamp over the M400 and align with
the existing bolt holes in the plastic bulkhead.
The KTC and KPE devices can be zip-tied to a suitable anchoring position.
