54 Appendices
Appendix O – Recommended CAN Collect
Configuration
The following configuration is recommended for connecting multiple PLM units
to an ADL.
Master Unit (PLM 1)
CAN Message 1 Message Rate OFF
CAN Message 2 Message Rate OFF
CAN Message 3 Message Rate OFF
CAN Message 4 Message Rate OFF
Base Address Hex 460 Collect Master
Message Rate At least 1 per second
Slave Units (PLM 2 to PLM 16)
Address Format Standard
Compound ID 00
Message Rate Same as PLM 1 Collect
Master Message Rate
CAN Message 1
Address PLM 2 = Hex 461
PLM 3 = Hex 462
PLM 4 = Hex 463
PLM 5 = Hex 464
PLM 6 = Hex 465
PLM 7 = Hex 466
PLM 8 = Hex 467
PLM 9 = Hex 468
PLM 10 = Hex 469
