MoTeC PLM User Manual
Page 49
MoTeC
Appendices
49
Message 2
Byte
Name
Scaling
0
Compound ID – user defined,
default 1
N/A
1:2
Ipn (Normalised pump cell
current)
Hi:Lo * 1 = X µA
3
Vs (Sense voltage)
Byte*5 = X mV
4
Vp (Pump cell voltage)
Byte * 10000 / 255 – 5000 = X
mV
5
Reserved
N/A
6:7
Ip (Raw pump cell current)
Hi:Lo * 1 = X µA
Message 3
Byte
Name
Scaling
0
Compound ID – user defined,
default 2
N/A
1
Bosch calibration resistor
Byte*1 = X ohm
3
NTK calibration resistor
Byte*1 = x.x kohm
4
Reserved
N/A
5
Reserved
N/A
6
Battery Voltage
Byte*1 = x.xV
Sensor voltage within
limits
1
7
Sensor in control
Sensor voltage outside
limits
0
