MoTeC PLM Communications 23
For use with MoTeC equipment (ADL or M800), the selected table must be
setup for Lambda with 3 decimal places. Other table setups should only be
used for interfacing with third party equipment.
Configuring Basic CAN with an ADL
To connect a small number of PLM units (maximum of six) to an ADL, the ADL
must use one CAN template (PLM#1 to PLM#6) for each PLM.
The PLM units must be configured as follows to match the ADL templates.
Output To Transmit LA V1, with 3 decimal places in the table
Address Format Standard
Address As per ADL template (460 to 465)
Compound Id Message 1 = 0
Message 2 = 1
Message 3 = 2
Message 4 = 3
Message Rate Message 1 = User defined
Message 2 = User defined
Message 3 = User defined
Message 4 = User defined
Collect Master = Off
Configuring basic CAN with an M800
Up to 12 PLM units can transmit to an M800 ECU if configured as follows:
Output To Transmit LA V1, with 3 decimal places in the table
Address Format Standard
Address PLM 1 = 460
PLM 2 = 461
….
PLM 12 = 46F
