Specifications
Specifications
Meter
Power Supply
Input Voltage Range
7 to 16Volts
Input current
60mA typical, backlight off
110mA typical, backlight on
Plus sensor heater current
Protection
Reverse polarity protected
Load Dump Clamp
Max 40V at 100 Amp 100msec
Sensors
Sensors
1
Compatible Types
Bosch LSU 4/ Bosch LSU 4.2/ NTK UEGO
Calibration Methods
Automatic using sensor’s built in calibration resistor
Manual Table Entry
Known Oxygen Environment
Calibration Constant
Type Detection
Manual
Sensor Thread
M18 x 1.5
Max Exhaust Temp
850 deg
Normal Temp Range
150 – 800 deg
Measurements
Lambda
0.7 to 32.0
0
2
0 to 22%
A/F Ratio
Fuel dependant (see lambda range)
Accuracy
+/- 1.5% (sensor specific)
