Appendices
Appendix D – PLM Connector Details
Sensor Connector - Male D9
1
Battery +12 Power (Note 2)
2
Heater +
3
Rc
4
Ip
5
Sensor Common
6
Battery 0V Power
7
Heater –
8
Vs
9
Ipr
Auxiliary Connector – Female D9
1
CAN Hi (Note 3)
2
RS232 Tx
3
RS232 Rx
4
Digital Input 1
5
Comms 0V
6
CAN Lo (Note 3)
7
Digital Input 2
8
Analog out + (Note 4)
9
Analog out – (Note 4)
Note1: Extension of Standard Sensor Loom
The length of the standard loom supplied for connection of the PLM to a sensor
is 2.5m. Longer looms are available from MoTeC by request.
It is not recommended that the loom is extended by using a standard serial
cable. These are unable to supply the current required by the sensor. If an
extension is made, the wire thickness must be at least 20 gauge.
Note 2: Power Supply Current
If using a power supply other than the vehicle battery, start-up current for the
sensor is up to 5A, though operating current is much lower than this, 0.5 – 1
Amps, depending on exhaust gas temperature.
