MoTeC Appendices 33
Appendix C – PLM CAN Diagnostic Codes
These are the bit field descriptions for the diagnostic error groups that are sent
to the ADL via the CAN link.
Diagnostic Group 1
1: No Sensor
2: Sensor Hot
4: Sensor Cold
8: Sensor Faulty
32: Warm Up
64: Ref voltage out of range
Diagnostic Group 2
These codes correspond to those displayed by the PLM.
1 (C-1) - Checking Operation.
2 (C-2) - Control Initialization.
4 (C-3) - Warm Up.
8 (C-4) - No heater detected.
16 (C-5) - User Stop (sensor turned off via digital input).
32 (C-6) - Sensor Protection Shutdown.
