Appendix A: General Specifications
Physical
Case Size
147mm x 105mm x 40mm (5.8in x 4.1in x 1.6in)
Weight
M400, M600, M800: 0.50 kg (1.10lb)
M880: 0.525kg (1.16 lb)
Power Supply
Operating Voltage: 6 to 22 Volts DC
Operating Current: 0.5 Amps Max (excluding sensor and load currents)
Reverse Battery Protection via External Fuse
Battery Transient Protection
Operating Temperature
Internal Temperature Range: -10 to 80
°C (14 to 176°F)
Ambient Temperature Range: -10 to 70
°C (14 to 158°F) typical, depending
on output loading
