34 Initial Setup
Crank Reference Teeth (CRT)
Crank Index Position (CRIP)
These parameters are dependant on the type of trigger system. Refer to the
appropriate MoTeC Trigger drawing, or Ignition System drawing.
Note that the trigger sensor type (Hall / Mag, Edges etc) must be setup in the
Sensor Setup screens.
Ignition
Ignition Type (IGN)
Number of Coils (COIL)
Ignition Dwell Time (DELL)
Ignition Delay Time
These parameters are dependant on the type of Ignition Module. Refer to the
appropriate MoTeC Ignition Module drawing, or Ignition System drawing.
Sensor Setup
Throttle Position Sensor Hi / Lo
TPLO Throttle Position LO (Closed Throttle)
TPHI Throttle Position HI (Wide Open Throttle)
The Throttle HI and LO points must be set every time the throttle position
sensor is moved or replaced so that the throttle can be correctly scaled
between 0 and 100%.
REF/SYNC Sensor Setup
The REF/SYNC setup parameters must be set to suit the trigger sensors.
Refer to the MoTeC Trigger drawings for details.
Sensor Calibrations
The sensors calibrations must be set to suit the connected sensors.
Refer to the ECU Manager help screens for details.
