4 sr107 front and rear views – Chenbro SR107 Series - Installation User Manual
Page 7
SR209/105/107 USER’S GUIDE
Revision: 1.0
7
5.25” shielding
Plates
3.5” FDD
Carrier
Side Cover
Thumbscrew
Optional Hotswap
Cage and Non-
Hotswap Cage
2 port USB
Bracket
Optional 5.25” to
3.5” Bracket
SR107 Front View
SR107 Rear View
Changeable PSU
Bracket for PS/2
or N+1 Redundant
Optional 120mm
Rear Fan
Support
Kensington Lock
Slot bracket with
ventilation holes
1.4 SR107 Front and Rear Views
