Page 27
SR209/105/107 USER’S GUIDE
Revision: 1.0
2 7
3.4 Installing HDD and HDD Cage
I. Before start
There are two types of HDD drive cages equipped with SR209,
SR105, and SR107, and exist a little bit differences for each product
model. These differences are detailed as table below.
Hotswap Cage
SR209/SR105
80mm Fan Holder(1)
Support
Up&down
N/A
Left& Right
Location of thumbscrews(2)
SR107
#6-32*D12
#6-32*D8
Type of thumbscrews(3)
Non-hotswap Cage
SR209/SR105
92mm front fan(4)
Front
Up&down
Front
Left& Right
Location of thumbscrews(5)
SR107
1
2 3
4
4
5
5
SR209/105 Hotswap Cage
SR107 Hotswap Cage
SR209/105 Non-Hotswap Cage
SR107 Non-Hotswap Cage
2 3
