SR209/105/107 USER’S GUIDE
Revision: 1.0 2 6
III. SR107 Side Cover
Remove the front bezel.
Refer to the previous section
for detailed instructions.
Loosen the three thumbscrews(1) of
side cover.
Slide the side cover toward until it is
stopped(2), then upward before
taking it off from the chassis body.
1
2
Figure 3-7
Figure 3-8
(a).
(b).
(c).
