Chenbro SR107 Series - Installation User Manual
Page 13
SR209/105/107 USER’S GUIDE
Revision: 1.0
1 3
1.10 SR105 Side View
1
2
3
4
5
6
7
8
9
Non-Hotswap Cage
Hotswap Cage
No.
Description
1
2
3
4
5
6
7
8
9
10
Easy bezel removal design
Screws for slide rail installation
Non-Hotswap HDD Cage
Optional 92mm fan
Add-on card retainer
Support 12” x13” server board
Optional screwless holder
Optional 120mm rear fan
Optional PS/2 or Mini-Redundant
10
6 pcs 5.25” slide rails
80mm fan holder
optional 92mm fan
