7 sr209 front& rear views – Chenbro SR107 Series - Installation User Manual
Page 10
SR209/105/107 USER’S GUIDE
Revision: 1.0
1 0
SR209 Front View
SR209 Rear View
5.25” shielding
Plates
Optional 5.25” to
3.5” Bracket
Optional Hotswap
Cage and Non-
Hotswap Cage
2 port USB
Bracket
Front ventilation
holes
Optional Single PS/2
ATX12V and EPS12V
PSU
Slot bracket with
ventilation holes
Optional 120mm
Rear Fan
Support
Kensington Lock
1.7 SR209 Front& Rear Views
