9 sr105 front& rear views – Chenbro SR107 Series - Installation User Manual
Page 12
SR209/105/107 USER’S GUIDE
Revision: 1.0
1 2
SR105 Front View
SR105 Rear View
5.25” shielding
Plates
Optional 5.25”
to 3.5” Bracket
Optional Hotswap
Cage and Non-
Hotswap Cage
2 port USB
Bracket
Front ventilation
holes
Optional Single
PS/2 or Mini-
Redundant PSU
Slot bracket
with ventilation
holes
Optional 120mm
Rear Fan
Support
Kensington Lock
1.9 SR105 Front& Rear Views
Side cover
thumbscrews
