5. REMOTE INTERFACE REFERENCE
5.1 Introduction
An Introduction to the SCPI Language
SCPI (Standard Commands for Programmable Instruments) is an ASCII-based instrument
command language designed for test and measurement instruments. SCPI commands are based on
a hierarchical structure, also known as a tree system. In this system, associated commands are
grouped together under a common node or root, thus forming subsystems. A portion of the
SOURCE subsystem is shown below to illustrate the tree system.
SOURce:
FREQuency:
STARt {<frequency>|MINimum|MAXimum}
FREQuency:
STARt? [MINimum|MAXimum]
FREQuency:
STOP {<frequency>|MINimum|MAXimum}
FREQuency:
STOP? [MINimum|MAXimum]
SOURce is the root keyword of the command, FREQuency is the second-level keywords, and
STARt and STOP are third-level keywords. A colon (: ) separates a command keyword from a
lower-level keyword.
Preparations for Remote Operation
The Arbitrary/Function Generator series 4080 can be remotely controlled from a PC via the
standard RS232 interface. Make sure to configure the RS232 interface to match the settings on your
PC by setting the parameters in the Systems menu accordingly. The instrument enters the remote
state after any remote command is received at which time all keys except of the 【Local】 key (Shift)
are locked When in Remote mode, the instrument can be returned to Local mode by pressing the
【Local】 key or by sending a “LOCAL instruction via the RS232 interface.
5.2 Overview and syntax of SCPI instructions
This section summarizes the SCPI commands available to program the function generator over the
remote interface. Refer to the later sections in this chapter for more details on each command.
Throughout this manual, the following conventions are used for SCPI command syntax.
•
Square brackets ([ ]) indicate optional keywords or parameters.
• Braces ({ }) enclose parameters within a command string.
• Triangle brackets (< >) indicate that you must substitute a value for the enclosed parameter.
• A vertical bar (|) separates multiple parameter choices.
Command Summary
APPLY instruction
