4080 series Function & Arbitrary/Function Generators –Instruction Manual
32
POWER ON —> ADDRESS —> OUT Z —> INTERFACE—>….
…………BAUD —> PARITY —> BEEP
P2: phase value #2
SPACE T PSK rate
TRIG Trigger source for PSK
Trigger source “TRIG”
Select internal signal and external input signal 1: INT or 2: EXT. The default of the instrument is
internal. In internal mode, the phase of the output signal shifts according to the PSK rate parameter.
In external trigger mode, the trigger signal is applied to the Ext. Trig” Input terminal on the rear
panel. In external trigger mode, the trigger signal applied to the trigger input terminal on the rear
panel determines the PSK rate. Logical “high” of the trigger signal is associated with phase value #2,
while the “Low” level of the trigger signal is associated with phase value #1.
Phase 1 “P1”
The first start phase value of the PSK output signal.
Input range of phase 1 and phase 2 is º0.0º~ 360.0º.
Phase 2 “P2”
The second start phase value of the PSK output signal.
Input range of phase 1 and phase 2 is 0.0º~ 360.0º.
Spacing time “SPACE T”
PSK rate: Range is 0.1ms ~ 800s.
PSK example
Configuration: Sine signals with 600 kHz output frequency, 2V amplitude, phase alternating
between 90.0º and 180.0º, PSK rate is 10ms
Press【FSK/PSK】 (2 times if necessary to enter PSK mode)
Press【Freq/Period】, enter【6】 【0】【0】【kHz】 (set waveform frequency)
Press【Ampl/Duty】, enter【2】 【V】 (set waveform amplitude)
Press【shift】 【sine】 (set waveform)
Press【menu】, select “TRIG”, enter【1】 【N】, (set trigger mode as internal)
Press【menu】, select “P1”, enter【9】 【0】【N】 (set phase 1)
Press【menu】key, select “P2”, enter【1】 【8】【0】【N】 (set phase 2)
Press【menu】, select “SPACE T”, enter【1】 【0】【ms】 (set PSK rate)
4.7 Set System Parameters
Press【Shift】and【system】to enter the Systems menu. “SYSTEM” will flash on the display.
Repeatedly press【menu】to cycle through the system parameters indicated below.
