4080 series Function & Arbitrary/Function Generators –Instruction Manual
13
Waveform states
Sine waveform is enabled (,main waveform)
Square waveform is enabled (main waveform)
Triangle waveform is enabled
Ramp waveform is enabled
Arb Arbitrary waveform mode is enabled
Frequency Measurement/Totalize states
Filter: Low Pass Filter is enabled
ATT: Input Attenuator is enabled
GATE: Gate received trigger
Function Generator states
Adrs: The instrument is in remote state.
Trig: Function Generator is waiting for a single trigger or external trigger.
FM: FM modulation is enabled
AM: AM modulation is enabled
Sweep: Sweep mode is enabled
Ext: Generator is configured for external signal input
Freq: Frequency measurement function is enabled
Count: Totalize function is enabled
FSK: FSK (frequency shift keying) modulation is enabled
◄FSK: PSK modulation is enabled
Burst:
Burst mode enabled.
Offset: DC offset of output signal is not 0.
Shift: Shift key has been pressed, Shift mode is active
Rmt: The instrument is in remote state.
3.13 Description of front panel keys
【shift】key
Access secondary functions or to enter units “seconds”, Vpp and “N”
Numerical key pad:
Keys are used for direct entry of numerical values. Keys【0】 【 ●】 【-】are assigned secondary
functions to enter the systems menu, reset the unit to its default values or revert to Standard
Waveform (“SW”) mode.
【 ◄】【►】arrow keys
The primary function is to move the flashing digit left or right or to select the desired arbitrary
waveform from the Arb List (secondary function). When in Counter Mode, these 2 keys are
used to start/stop or reset/resume the counter.
【Freq/Period】key:
Toggle between frequency and period display (primary function) or to enable sine waveform.
【Ampl/Pulse Width】key:
Display and adjust the amplitude of waveforms or, when in pulse mode, toggle the display
